| 纠错时间 | 修改字段 | 原参数 | 修改后参数 | 说明 / 状态 |
|---|---|---|---|---|
No parameter correction records exist. If you spot inaccurate data, click the flag icon at the end of the corresponding row to submit feedback. | ||||
mm / 英寸自动双单位换算 · 工程采购基础规格
| Overall dimensions | 1750 x 650 x 800 mm | |
|---|---|---|
| Seat height from floor | 430 mm | |
| Individual seat width | 520 mm | |
| Seat depth | 480 mm | |
| Backrest height above seat | 370 mm | |
| Armrest height above seat | 220 mm | |
| Leg base spread width (front to back) | 600 mm | |
| Perforated panel mesh size | 6 mm | |
| Frame tube wall thickness | 1.5 mm | |
| Under-seat clearance from floor | 320 mm | |
| Perforated panel mesh aperture | 6 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
净重 / 最大承重 / 适用人数 / 耐久性能
| Product net weight | 28 kg | |
|---|---|---|
| Static load capacity per seat | 200 kg | |
| Recommended maximum user weight per seat | 150 kg | |
| Surface abrasion resistance | 5000 cycles | |
| Floor glide adjustable height | 15 mm | |
| Design service life | 8 years | |
| Surface powder coating abrasion resistance | 5000 cycles | |
| Backrest static load resistance | 760 N | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
| Seat panels | 1.2mm cold-rolled steel sheet with perforated texture, full powder coated silver finish | |
|---|---|---|
| Backrest panels | 1.2mm cold-rolled steel sheet with perforated texture, matching silver powder coated finish | |
| Armrests | 2.0mm formed steel tube, silver powder coated, integrated curved open-loop design | |
| Supporting frame | 40x20mm rectangular steel tube, silver powder coated, connects individual seat/back modules | |
| Leg bases | Cast aluminum alloy with silver powder coated finish, Y-shaped splayed 3-leg design per end | |
| Connection hardware | Zinc-plated steel bolts and nuts, anti-loosening design for public high-frequency use | |
| Floor glides | Reinforced nylon base with TPE non-slip pad, threaded adjustable stud | |
| Surface finish | Epoxy polyester powder coating, anti-rust treatment, matte silver finish | |
| Horizontal supporting beam | 40x20mm rectangular steel tube, silver powder coated, connects individual seat/back modules into a single gang unit | |
| Seat-back connection brackets | 2.5mm stamped steel, zinc plated for corrosion resistance, secured with anti-loosening fasteners | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
| Seating capacity | 3 individual separated seats | |
|---|---|---|
| Ventilation performance | Perforated seat and back panels allow continuous air flow | |
| Floor leveling | 6 adjustable threaded nylon glides at each leg end | |
| Cleaning access | Smooth rounded frame edges and open perforated surface design | |
| Structural rigidity | Dual Y-shaped end leg frames connected by full-length horizontal crossbeams | |
| Armrest support | Fixed integrated armrests at both outer ends of the unit | |
| Installation requirement | Freestanding placement, optional floor anchor bolts for high-security areas | |
| Modular connection | End frames have pre-punched connection holes to link multiple units in a row | |
| Sanitation access | Smooth rounded frame edges and fully open perforated surface design with 320mm under-seat clearance | |
| Installation flexibility | Freestanding placement as standard, with pre-drilled M8 anchor holes on leg bases for permanent floor fixing | |
| Modular row connection | End leg frames have pre-punched M6 connection holes to link multiple units end-to-end | |
| Backrest tilt angle from vertical | 10° |
经核验的外箱 / 毛重 / 组装 / 装柜数据
| Number of shipping cartons | 1 | |
|---|---|---|
| Shipping carton dimensions | 1780 x 680 x 520 mm | |
| Gross shipping weight | 31 kg | |
| Shipping volume per unit | 0.63 CBM | |
| Assembly time on site | 10 minutes | |
| 20ft GP container loading capacity | 42 units | |
| 40ft HQ container loading capacity | 105 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
推荐空间 / 目标用户 / 使用方式
| Medical facility waiting areas | Suitable for hospital outpatient clinics, emergency departments and dental practice waiting zones | |
|---|---|---|
| Transportation hub seating | Ideal for airport terminals, railway stations and bus terminal waiting halls | |
| Public service office lobbies | Appropriate for bank branches, government service centers and postal office waiting areas | |
| Commercial public spaces | Suited for shopping mall rest zones, exhibition halls and visitor center waiting areas | |
| Educational institution common areas | Applicable for university administration lobbies, training center corridors and library waiting zones | |
| Outdoor covered waiting zones | Usable in covered bus stops, smoking shelters and building entrance canopies | |
| Covered outdoor waiting zones | Usable in covered bus stops, smoking shelters and building entrance canopies | |
| Recommended Matching Desk Size | 2.4 m executive desk |
欧洲市场准入与化学品要求
| EN 13761:2002 | Furniture - Seating for public areas - Test methods and requirements, applicable for strength, stability and durability verification for high-traffic waiting seating | |
|---|---|---|
| EN 1022:2018 | Furniture - Seating - Determination of stability, applicable for verifying tip resistance when occupants lean on armrests or seat edges | |
| EN 16139:2013 | Furniture - Strength, durability and safety - Requirements for non-domestic seating, applicable for public waiting area use case compliance |
美国及加拿大办公家具标准
| ANSI/BIFMA X5.1-2017 | General Purpose Office Chairs - Tests, applicable for static load, backrest strength and leg durability verification for commercial seating applications |
|---|
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable for dimensional tolerance, surface finish and structural stability verification | |
|---|---|---|
| GB/T 10357.2-2013 | Furniture mechanical performance test for seating, applicable for static load, impact and durability testing of public waiting seats | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for verifying lead and heavy metal content in powder coating finishes | |
| GB/T 10357.3-2013 | Furniture mechanical performance test for seating backrests and armrests, applicable for verifying strength of leaning and arm support components |
本产品须满足以下技术参数要求： 1. GB/T 3324-2017：General technical requirements for metal furniture, applicable for dimensional tolerance, surface finish and structural stability verification； 2. GB/T 10357.2-2013：Furniture mechanical performance test for seating, applicable for static load, impact and durability testing of public waiting seats； 3. GB 18584-2001：Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for verifying lead and heavy metal content in powder coating finishes； 4. GB/T 10357.3-2013：Furniture mechanical performance test for seating backrests and armrests, applicable for verifying strength of leaning and arm support components； 最终交付参数、检测报告和验收标准以双方采购合同为准。
以下文件均根据当前已发布商品参数实时生成。
直接下载英文参数报告，可选择公制或英制单位。
导出全部商品信息与参数模块，文件内容统一使用英文。
包含英文标题、规格、材质、标准和采购字段，可用于国际平台刊登。
生成申报品名、材质、用途、尺寸及海关申报要素。
打开导出工具这款无品牌三座全金属公共等候椅型号为WT-3S-MTL-001，采用整洁的线性联排座椅布局，整体为均匀的哑光银色粉末涂层饰面。三个清晰划分的独立座椅通过靠背处的细微间隙分隔，界定个人空间；单元两端设有与Y形外张椅腿组件一体化的固定式弧形开环扶手。结构上，座面与靠背采用冲孔冷轧钢板，由矩形钢管水平横梁支撑，搭配成型钢制扶手、铸铝合金椅腿底座，以及配有防滑TPE垫的增强尼龙地脚。所有接缝采用防松镀锌钢制紧固件固定，冲孔金属基底上方的软垫座面与靠背段下方设有内部弯曲胶合板支撑。冲孔面板设计可实现稳定空气流通，避免短时等候时热量积聚；座下开放式空隙无封闭积尘死角，无需拆卸即可快速彻底清洁消毒。可调螺纹地脚可在不平整的硬质地面上稳定放置，且不会刮擦地面；端框上的预冲孔可将多个单元连接成加长的连续排，而预钻锚固点可在高安全需求场所实现永久地面固定。固定的微倾靠背提供腰部支撑，帮助使用者保持放松的直立坐姿；重型全金属结构几乎无需日常维护。这款椅子适用于各类高人流量场所，包括医疗机构等候区、机场与火车站航站楼、银行与政务服务大厅、商场休息区、高校公共区域，以及有遮蔽的半户外等候区，比如带顶棚的公交站或建筑入口雨棚下。其中性金属饰面可与现代商业室内方案完美适配，耐用表面可抵御高频日常使用造成的磨损。采购请注意：批量下单前，最终材质等级、焊接规格与涂层厚度需通过供应商物料清单确认。该产品采用防护包装发货，现场组装量极小，仅需安装地脚即可布置。规划大规模安装时，请考虑模块连接兼容性以定制排长度，并在存在较高人为破坏或冲击风险的场所选配锚固五金件。在标准维护条件下、常规高人流量使用场景中，该设计使用寿命为8年，可满足公共座椅需求的可靠长期部署。
